Key features
- Supports MIG/MAG, MMA and TIG Lift
- Four-wheel drive wire feeder
- Program switching from the torch trigger
- Optional water cooler — no technician needed
- Handles thin to thick materials
- 3-year warranty
SKU MIL3300000002
BlueFab® C350i Multiprocess Welding Machine
The BlueFab® C350i is an industrial multiprocess welding machine based on inverter technology, supporting MIG/MAG, synergic MIG/MAG, DC MMA and DC TIG Lift processes. The unit comes with a running gear and integrated gas bottle shelf, and features a wire feeder with an industrial-grade four-wheel drive mechanism in a compact metal casing. The operator has direct access to four pre-programmed or customised programs from the front panel, and trigger select functionality allows program switching from the torch trigger without returning to the wire feeder. An optional water cooler can be installed without a service technician. The machine is suited for maintenance and repair, manufacturing, shipbuilding and general construction. It handles thin to thick materials with 0.6–1.6 mm solid or cored wires. The amperage range is 30–350 A, with a rated output of 320 A / 30 V at 60% duty cycle. Warranty period is 3 years.
- Processes
- MIG/MAG, Synergic MIG/MAG, DC MMA, DC TIG Lift
- Input Voltage
- 400 V
- Input Phase
- 3 phases
- Input Frequency
- 50/60 Hz
- Amperage Range
- 30 A – 350 A
- Rated Output
- 320 A / 30 V @ 60% duty cycle
- Max Open Circuit Voltage
- 45 VDC
- Wire Diameter
- 0.6–1.6 mm (solid and cored wires)
- Net Width
- 487 mm
- Net Height
- 857 mm
- Net Depth
- 990 mm
- Net Weight
- 56.6 kg
- Warranty
- 3 Years Miller's True Blue Warranty
- Brand
- Miller
